Spur Gearbox DC Geared Motor
Gearmotors and Gearboxes

SG20-DC1625012

Spur Gearbox DC Geared Motor Diameter Ø20mm Reduction drive
  • Free Delivery in 3-5 Working Days
  • Flexible Rental Period
  • Free Easy Returns
Send a Request

Specifications

Model
SG20-DC1625012
Gearbox Model
SG20
Gearbox Type
Spur Gearboxes
Motor in Use
DC1625012
>> Motor details
Type of Motor
Brushed DC Motors
Gearbox Diameter (Ø mm)
20
Gearhead Data
Reduction RatioNumber of
Gear Stages		Gearbox Housing
Length (mm)		No-load Speed
(rpm)		Nominal Speed
(rpm)		Nominal Torque
(gf.cm)
29
4
17.9
290
235
0.3
31
4
17.9
270
220
0.3
56
5
17.4
150
120
0.5
73
5
17.4
115
95
0.7
107
6
18.9
80
65
0.9
182
6
18.9
48
38
1.5
268
7
20.4
33
26
2
349
7
20.4
25
20
2.5
456
7
20.4
19
16
2.5
488
7
20.4
18
15
2.5
