Spur Gearbox DC Geared Motor
Gearmotors and Gearboxes

SG33-DC3323024

Spur Gearbox DC Geared Motor Diameter Ø33mm Reduction drive
  • Free Delivery in 3-5 Working Days
  • Flexible Rental Period
  • Free Easy Returns
Send a Request

Specifications

Model
SG33-DC3323024
Gearbox Model
SG33
Gearbox Type
Spur Gearboxes
Motor in Use
DC3323024
>> Motor details
Type of Motor
Brushed DC Motors
Gearbox Diameter (Ø mm)
33
Gearhead Data
Reduction RatioNumber of
Gear Stages		Gearbox Housing
Length (mm)		No-load Speed
(rpm)		Nominal Speed
(rpm)		Nominal Torque
(gf.cm)
19
3
20
240
210
0.3
48
4
20
95
80
0.7
120
5
22.5
38
34
1.4
301
6
27.5
15
13
3.5
752
7
27.5
6
5
4
