Spur Gearbox DC Geared Motor
Gearmotors and Gearboxes

SG27-DC2419012

Spur Gearbox DC Geared Motor Diameter Ø27mm Reduction drive
  • Free Delivery in 3-5 Working Days
  • Flexible Rental Period
  • Free Easy Returns
Send a Request

Specifications

Model
SG27-DC2419012
Gearbox Model
SG27
Gearbox Type
Spur Gearboxes
Motor in Use
DC2419012
>> Motor details
Type of Motor
Brushed DC Motors
Gearbox Diameter (Ø mm)
27
Gearhead Data
Reduction RatioNumber of
Gear Stages		Gearbox Housing
Length (mm)		No-load Speed
(rpm)		Nominal Speed
(rpm)		Nominal Torque
(gf.cm)
26
3
15
250
220
0.4
42
4
15
155
140
0.6
73
4
15
90
80
1
