Spur Gearbox DC Geared Motor
Gearmotors and Gearboxes

SG25-DC2419012

Spur Gearbox DC Geared Motor Diameter Ø25mm Reduction drive
  • Free Delivery in 3-5 Working Days
  • Flexible Rental Period
  • Free Easy Returns
Send a Request

Specifications

Model
SG25-DC2419012
Gearbox Model
SG25
Gearbox Type
Spur Gearboxes
Motor in Use
DC2419012
>> Motor details
Type of Motor
Brushed DC Motors
Gearbox Diameter (Ø mm)
25
Gearhead Data
Reduction RatioNumber of
Gear Stages		Gearbox Housing
Length (mm)		No-load Speed
(rpm)		Nominal Speed
(rpm)		Nominal Torque
(gf.cm)
4
2
17
1600
1450
0.08
10
3
19
650
580
0.16
21
4
19
320
270
0.3
34
5
21
190
170
0.5
47
5
21
140
120
0.6
78
6
23
85
75
0.9
103
6
23
65
55
1.2
130
7
25
50
45
1.5
227
7
25
30
25
2.2
499
8
27
13
12
3
