Spur Gearbox DC Geared Motor
Gearmotors and Gearboxes

SG1412-DC1226006

Spur Gearbox DC Geared Motor Size 14×12mm Reduction drive
  • Free Delivery in 3-5 Working Days
  • Flexible Rental Period
  • Free Easy Returns
Send a Request

Specifications

Model
SG1412-DC1226006
Gearbox Model
SG1412
Gearbox Type
Spur Gearboxes
Motor in Use
DC1226006
>> Motor details
Type of Motor
Brushed DC Motors
Gearbox Size (mm)
14×12
Gearhead Data
Reduction RatioNumber of
Gear Stages		Gearbox Housing
Length (mm)		No-load Speed
(rpm)		Nominal Speed
(rpm)		Nominal Torque
(gf.cm)
30
4
12
340
285
0.22
63
4
12
190
158
0.44
115
5
12
105
92
0.6
130
5
12
95
78
0.8
150
5
12
80
66
0.9
250
5
12
50
42
1
350
5
12
35
31
1
