Planetary Gearbox BLDC Geared Motor
Gearmotors and Gearboxes

PG36-EC3657024

Planetary Gearbox BLDC Geared Motor Ø36mm Reduction drive
  • Free Delivery in 3-5 Working Days
  • Flexible Rental Period
  • Free Easy Returns
Send a Request

Specifications

Model
PG36-EC3657024
Gearbox Model
PG36
Gearbox Type
Planetary Gearboxes
Motor in Use
EC3657024
>> Motor details
Type of Motor
Brushless DC Motors
Gearbox Diameter (Ø mm)
36
Gearhead Data
Reduction RatioNumber of
Gear Stages		Gearbox Housing
Length (mm)		No-load Speed
(rpm)		Nominal Speed
(rpm)		Nominal Torque
(gf.cm)
3.7
1
27.3
1568
1135
1.48
5.2
1
27.3
1115
808
2.08
13.7
2
35.4
423
307
4.8
19.2
2
35.4
302
219
6.72
27
2
35.4
215
156
9.45
50.5
3
43.5
115
83
15.15
71
3
43.5
82
59
21.3
100
3
43.5
58
42
30
139
3
43.5
42
30
41.7
187.5
4
54.6
31
22
46.88
263
4
54.6
22
16
50
370
4
54.6
16
11
50
520
4
54.6
11
8
50
731
4
54.6
8
6
50
