PG16-ECL1620012
Planetary Gearbox BLDC Geared Motor Ø16mm Reduction drive
-
Free Delivery in 3-5 Working Days -
Flexible Rental Period
-
Free Easy Returns
Specifications
Model | PG16-ECL1620012 | |
Gearbox Model | PG16 | |
Gearbox Type | Planetary Gearboxes | |
Motor in Use | ECL1620012 | >> Motor details |
Type of Motor | Brushless DC Motors | |
Gearbox Diameter (Ø mm) | 16 |
Gearhead Data
| Reduction Ratio | Number of Gear Stages | Gearbox Housing Length (mm) | No-load Speed (rpm) | Nominal Speed (rpm) | Nominal Torque (gf.cm) |
|---|---|---|---|---|---|
|
4
|
1
|
16.3
|
3750
|
3125
|
0.05
|
|
14
|
2
|
20
|
1071
|
892
|
0.14
|
|
16
|
2
|
20
|
937
|
781
|
0.16
|
|
19
|
2
|
20
|
789
|
657
|
0.19
|
|
29
|
2
|
20
|
517
|
431
|
0.3
|
|
53
|
3
|
23.75
|
283
|
235
|
0.47
|
|
62
|
3
|
23.75
|
241
|
201
|
0.55
|
|
72
|
3
|
23.75
|
208
|
173
|
0.64
|
|
84
|
3
|
23.75
|
178
|
148
|
0.75
|
|
104
|
3
|
23.75
|
144
|
120
|
0.93
|
|
128
|
3
|
23.75
|
117
|
97
|
1.15
|
|
157
|
3
|
23.75
|
95
|
79
|
1.41
|
|
231
|
4
|
27.4
|
64
|
54
|
1.73
|
|
284
|
4
|
27.4
|
52
|
44
|
2.13
|
|
370
|
4
|
27.4
|
40
|
33
|
2.4
|
|
390
|
4
|
27.4
|
38
|
32
|
2.4
|
|
455
|
4
|
27.4
|
32
|
27
|
2.4
|
|
561
|
4
|
27.4
|
26
|
22
|
2.4
|
|
690
|
4
|
27.4
|
21
|
18
|
2.4
|
|
850
|
4
|
27.4
|
17
|
14
|
2.4
|
|
1014
|
5
|
31.05
|
14
|
12
|
2.4
|
|
1621
|
5
|
31.05
|
9
|
7
|
2.4
|
|
1996
|
5
|
31.05
|
7
|
6
|
2.4
|
|
3027
|
5
|
31.05
|
4
|
4
|
2.4
|
