Spur Gearbox DC Geared Motor
Gearmotors and Gearboxes

SG16-DC1226006

Spur Gearbox DC Geared Motor Diameter Ø16mm Reduction drive
  • Free Delivery in 3-5 Working Days
  • Flexible Rental Period
  • Free Easy Returns
Send a Request

Specifications

Model
SG16-DC1226006
Gearbox Model
SG16
Gearbox Type
Spur Gearboxes
Motor in Use
DC1226006
>> Motor details
Type of Motor
Brushed DC Motors
Gearbox Diameter (Ø mm)
15.5
Gearhead Data
Reduction RatioNumber of
Gear Stages		Gearbox Housing
Length (mm)		No-load Speed
(rpm)		Nominal Speed
(rpm)		Nominal Torque
(gf.cm)
10
2
11
1200
1000
0.08
20
4
11
600
500
0.14
35
4
11
340
285
0.25
63
4
11
190
158
0.44
86
4
11
140
116
0.5
115
5
11
105
92
0.5
150
5
11
80
73
0.5
250
5
11
50
46
0.5
360
5
11
35
33
0.5
