Planetary Gearbo DC Geared Motor
Gearmotors and Gearboxes

PG16-DC1226012

Planetary Gearbox DC Geared Motor Ø16mm Reduction drive
  • Free Delivery in 3-5 Working Days
  • Flexible Rental Period
  • Free Easy Returns
Send a Request

Specifications

Model
PG16-DC1226012
Gearbox Model
PG16
Gearbox Type
Planetary Gearboxes
Motor in Use
DC1226012
>> Motor details
Type of Motor
Brushed DC Motors
Gearbox Diameter (Ø mm)
16
Gearhead Data
Reduction RatioNumber of
Gear Stages		Gearbox Housing
Length (mm)		No-load Speed
(rpm)		Nominal Speed
(rpm)		Nominal Torque
(gf.cm)
4
1
15.1
3100
2450
0.03
16
2
18.7
770
600
0.11
29
2
18.7
430
335
0.2
62
3
22.4
200
150
0.4
104
3
22.4
120
90
0.6
198
3
22.4
65
48
1
231
4
26
55
40
1.2
370
4
26
35
26
2.2
850
5
29.7
15
12
2.4
1996
5
29.7
6
5
2.4
